1 FS-N Series
7
- Sensor Amplifier Network Manual -
CC-Link DeviceNet
Name Attribute
Data
type
Initial
value
Parameter range
Data
category
(Hex)
Data No.
(Hex)
InstID
AttrID
(Hex)
00
nn71
nn x 10+3
75 [Custom] Key Lock Status R/W INT 0
0: Unlock
1: Key Lock
2: PIN Code Lock
3: Communication Lock
nn72 76 [Custom] PIN Code R/W INT 0 0 - 9999
nn73 77 [Custom] Slide Switch Lock R/W INT 0
0: Unlock
1: Lock
nn74 78 [Custom] L-on/D-on (N.O./N.C.) R/W INT 0
0 : OUT1 : L-on / OUT2 : L-on
1 : OUT1 : D-on / OUT2 : L-on
2 : OUT1 : L-on / OUT2 : D-on
3 : OUT1 : D-on / OUT2 : D-on
nn75 79 [Custom] Power Mode R/W INT 1
0: HIGH SPEED (Response Time 50
μ
s)
1: FINE (Response Time 250
μ
s)
2: TURBO (Response Time 500
μ
s)
3: SUPER (Response Time 1ms)
4: ULTRA (Response Time 4ms)
5: MEGA (Response Time 16ms)
nn76 7A [Custom] Sensitivity Setting R/W INT 0
0: Normal Sensitivity Setting
1: Percentage Calibration
2: Zero-shift Calibration
nn77 7B
[Custom] Percentage Carib.
Target Value
R/W INT - 10 - 99 - +99
nn78 -
nn7F
7C - 83 System reserved - - - -
nn80
nn x 10+4
64 Group4 Entry count
*1
R INT 9 9
nn81 65 Output Timer (Output1) R/W INT 0
0: Timer Off
1: Off-delay Timer
2: On-delay Timer
3: One-shot Timer
nn82 66 Timer Value (Output1) R/W INT 10 1 - 9999
nn83 67 System reserved - - - -
nn84 68 Detection Mode (Output1) R/W INT 0
0: Normal Detection Mode
1: DATUM1 Mode
2: DATUM2 Mode
3: Area Detection Mode
4: Rising Edge Detection Mode
5: Falling Edge Detection Mode
nn85 69 DATUM Speed R/W INT 0
0: Level1 (Slow)
1: Level2 (Normal)
2: Level3 (Fast)
nn86 6A DATUM Warning Level R/W INT 50 0 - 100
nn87 6B Control Input R/W INT 0
0: Not use
1: External Calibration
2: Preset
3: Zero-shift
4: Reset
5: Transmission OFF
6: PAUSE Mode Transition
7: SLEEP Mode Transition
nn88 6C PAUSE Mode R/W INT 0
0: Always OFF
1: Always ON
2: Keep Output
nn89 6D Light Emission Power R/W INT 100
1 - 100
nn8A -
8F
6E - 73 System reserved - - - -
nn90 74 [Custom] Group4 Entry count
*1
R INT 9 9
nn91 75 [Custom] Output Timer (Output1) R/W INT 0
0: Timer Off
1: Off-delay Timer
2: On-delay Timer
3: One-shot Timer
nn92 76 [Custom] Timer Value (Output1) R/W INT 10 1 - 9999
nn93 77 System reserved - - - -
nn94 78
[Custom] Detection Mode
(Output1)
R/W INT 0
0: Normal Detection Mode
1: DATUM1 Mode
2: DATUM2 Mode
3: Area Detection Mode
4: Rising Edge Detection Mode
5: Falling Edge Detection Mode
